| Input Voltage (V) | 1 Phase 220V 50/60Hz |
| Input Capacity (KVA) | 15.0 |
| No-load voltage (V) | 60 |
| Output Current Range (A) | 30-280A |
| Duty Cycle (%) | 60% |
| Effeciency (%) | 85 |
| Protection Class | IP21S |
| Insulation Class | F |
| Applied Electrodes (mm) | 1.6-5.0 |
| Machine Size (mm) | 370x165x280 |
| Packing Size (mm) | 435x235x350 |
| Weight (Kg) | 10 |
